IDEAL INDUSTRIES INC.
500jr TAN TWISTER WIRE NUT #341/3#22-3#10AWG/WING/HEX HD
Aisle Number: 42
Bin Number: 01
Comfortable swept wings offer extra leverage and less effort on large wire combinations
Expanding square-wire spring supports a wide range of common wiring configurations
Durable copolymer shell expands for smooth, progressive tightening that provides dependable connections
Hexagonal top with ribbed cap allows for quick fingertip start as well as use of standard 5/16 in. nutdriver for fast installation
Quick take-up on even the toughest combinations, including solid-to-stranded
Chat with us now or give us a call for shipping costs at (773)283-2550. You can also place the order and our sales team will get back to you with shipping estimates within 24 hours.
Contact BE Atlas for Updated Pricing: (773) 283-2550
(BETA) GPT Name and Description (content under review - please confirm with B.E. Atlas before purchasing)
IDEAL Twister Wire Connectors, Model 341, Tan (500-Jar)
Model 341, Tan, 500 connectors per jar, Accepts 3 #22 to 3 #10 AWG wire combinations, Rated for 600 Volt maximum, CSA Listed, UL Listed, Connector Depth: 0.54 inches, Connector Height: 1.14 inches, Connector Width: 0.72 inches, See www.idealind.com or call Customer Assistance for warranty details.
Model 341, Tan, 500 connectors per jar, Accepts 3 #22 to 3 #10 AWG wire combinations, Rated for 600 Volt maximum, CSA Listed, UL Listed, Connector Depth: 0.54 inches, Connector Height: 1.14 inches, Connector Width: 0.72 inches, See www.idealind.com or call Customer Assistance for warranty details.
UPCiteMDB Info (Beta: please contact us for the most up-to-date information):
Title: Ideal Twister Wire Connectors Tan - Pack of 500
Barcode: 783250515875
Size/Weight: 2.46lb
Description: Twist On Wire Connector Color Tan For Conductor Material Copper Maximum Operating Temperature 221 Degrees F Maximum Voltage 600 V Minimum Wire Combination (2) 18 AWG Maximum Wire Combination (4) 10 AWG Contact Material Steel UL 94 Flammability Rating V-2 Standards CSA- C22.2 NO. 188 IEC 998-2 IEC 998-2-4 UL 486C W-S-610E Wire Connector Style Wing Insulation Material Polypropylene Maximum Single Wire Size 8 AWG Minimum Single Wire Size 22 AWG Overall Height 1.14 in
